POLEMOUNT

◀

▶

DESCRIPTION

Cheryong's Polemount transformers are highly reliable and manufactured as per the requirements of customers. They are expertly-designed, engineer-supported transformers which fully meet required standards. Wide range of standards and optional accessories are available for selections.

FEATURES

ㆍHigh reliability

ㆍProven technology

ㆍAdvanced manufacturing and testing facility

ㆍAvailable in both SiFe and Amorphous Core

SPECIFICATIONS

FREQUENCY	50/60Hz
HV	Up to 34,500GrdY/19,920V
LV	600V and Below
RATING	10~500kVA
IMPEDANCE	1.0 ~ 5.75%
MAX. BIL	150kV BIL
Core Design	Core/Shell Form
Standards	IEEE/IEC/NEMA
Insulation Oil	Mineral/Natural Ester
Tank Type	Mild Steel/Stainless Steel
Basic Components	HV/LV Bushings Pressure Relief Device Lifting Devices Ground Connectors Support Lugs
Optional	Wildlife Guard De-Energized Tap Changer Surge Arrester Dual-voltage Switch LV Circuit Breaker MagNex Interrupter Tap changer
